SINGLE SIM FCT GSM
The PREFCT range of FCT’s/GSM Addon Cards* are a premium range of Fixed Cellular Terminals/GSM Addon Cards* used to make and receive calls over a GSM/Edge network using the existing infrastructure of land line telephones and PBX.
The PREFCT range of FCT’s/GSM Addon Cards* are a highly Indigenised range of FCT’s/GSM Addon Cards*, designed and manufactured with India specific conditions in mind.
The FCT’s/GSM Addon Cards eliminate high call costs converting all calls to mobile – mobile calls, bringing down high network interconnectivity costs.
The FCT’s are designed to function with all major telephones and PBX brands available in India and are ideal for all small offices as not only enablers, but, also as add-ons to the existing infrastructure.
- Inbuilt CLI facility.
- Quad Band GSM supporting the entire range of 2G spectrum.
- Programmability to increase or decrease volume gain on telephone Mic.
- Programmability to increase or decrease volume gain on telephone receiver.
- Programmability to increase or decrease number of CLI digits and CLI gain to accommodate all EPABX systems.
- High gain 5 DB antenna/’s provided with the system to receive signal even in low signal areas.
- Design allows for maximum range of spectrum to receive and transmit signals from any mobile operator throughout the country.
- Compatible with all major telephones from all major telephone manufacturers.
- Compatible with EPABX systems from all major manufacturers.
GSM Addon Cards are compatable & can be added on to Premier – Paradigm range of PBX.
FCT Specifications
|
Specifications |
PREFCT - 1 |
PREFCT - 2 |
||||
|
Models |
GSM FCT for Voice Applications |
GSM FCT for Voice Applications |
||||
|
|
|
|
|
|
|
|
|
Mobile
Port |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
GSM SIM
Cards |
1 |
2 |
||||
|
|
|
|
|
|
|
|
|
Frequency
Bands |
Quad Band GSM850, EGSM900, DCS1800, PCS1900 |
|||||
|
|
|
|
|
|
|
|
|
FXS
Port/Telephone Port |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Connector |
RJ11 |
|||||
|
Dialing and Reception |
DTMF Dialing |
|||||
|
Caller
Line ID |
DTMF Presentation |
|||||
|
|
|
|
|
|
|
|
|
Powersupply |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input |
Internal Powersupply |
|||||
|
|
180-260 VAC @ 50Hz |
|||||
|
Power
Consumption |
3.5 W (Typical) |
5 W (Typical) |
||||
|
|
||||||
|
Other |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Size |
220x148x40 mm |
|||||
|
Weight |
500 Gms |
600 Gms |
||||
|
Mounting
Options |
Wall Mountable and Table Top |
|||||
|
Operating
Temperature |
0°C to +45°C |
|||||
